Professional 8-input HDMI live switcher with ISO recording, multiview, and built-in streaming for advanced multi-camera production.
| Specification | Details |
|---|---|
| Video Inputs | 8 × HDMI Inputs |
| Video Outputs | 3 × HDMI Outputs + USB-C Webcam Output |
| Total Inputs Supported | 8 HDMI + Media Sources |
| Supported Resolution | Up to 1080p60 |
| ISO Recording | Yes (All 8 Inputs + Program Output) |
| Recording Format | H.264 MP4 |
| Streaming | RTMP via Ethernet / USB |
| Audio Inputs | 2 × 3.5mm Stereo |
| Audio Outputs | 1 × 3.5mm Stereo |
| Audio Mixer | Built-in Digital Audio Mixer |
| Multi-View | Up to 16 Views |
| Keyers | 4 Chroma Keyers + 2 Downstream Keyers |
| DVE | 2 Digital Video Effects Engines |
| SuperSource | Yes |
| Media Players | 2 |
| Frame Sync | Yes (on all HDMI inputs) |
| USB Interface | USB-C (Webcam + Recording) |
| Network | Ethernet (Streaming, Control, Updates) |
| Power Consumption | Approx. 36W |
| Control Options | Hardware Panel + Software Control |
| Recording Storage | External USB Drives / SSD |
| Operating Temperature | 5°C to 40°C |
| Weight | Approx. 1.2 – 1.4 kg (Class Range) |
| Warranty | 1 Year Manufacturer Warranty |
