AVMatrix VS0601U Mini 6-Channel SDI/HDMI Multi-format Streaming Switcher

Be the first to review this product
₹63,990.00
In stock
SKU
VS0601U
Delivery availability

        Compact 6-channel SDI/HDMI video switcher with USB-C streaming, multiview monitoring, and professional live production features.

        Add to Wish List Add to Compare
        Video Mixer,
        More Information
        Specification Details
        Video Inputs 4 × 3G-SDI + 2 × HDMI
        Video Outputs 2 × SDI (PGM), 1 × HDMI (PGM), 1 × SDI AUX, SDI & HDMI Multiview
        USB Output USB-C (UVC Streaming Output)
        Supported Resolution Up to 1080p60
        Streaming Via USB-C to PC (Zoom, YouTube, OBS, etc.)
        Switching Type T-Bar, Auto, Cut
        Effects Mix, Fade, Wipe, PiP/PoP
        Audio Inputs 3.5mm Stereo + RCA + Embedded HDMI/SDI Audio
        Audio Outputs 3.5mm Stereo + RCA
        Audio Mixer Built-in Digital Audio Mixer with AFV
        Multiview 6-Source Multiview (HDMI & SDI)
        GPIO Tally Interface Support
        Frame Sync Yes (Auto format detection)
        Control Options Hardware Panel
        Latency Low Latency Switching
        Build Type Compact Metal Portable Design
        Dimensions Approx. 249 × 172 × 55 mm
        Weight ≈ 1.2 kg
        Warranty 2 Year Manufacturer Warranty
