Portable 6-channel SDI/HDMI video switcher with 15.6″ display, USB streaming, recording, and professional multi-camera production features.
| Specification | Details |
|---|---|
| Video Inputs | 4 × 3G-SDI + 2 × HDMI (Supports DVI/VGA/USB Inputs) |
| Video Outputs | 2 × HDMI (PGM), 3 × SDI (PGM/AUX), 1 × HDMI Multiview |
| Supported Resolution | Up to 1080p60 (HD Output), HDMI Input up to 4K60 |
| Display | 15.6″ Full HD IPS (1920 × 1080) |
| Streaming Output | USB-C (UVC/UAC) |
| Recording | SD Card (H.264, up to 1080p60) |
| Switching Type | T-Bar, Auto, Cut |
| Effects | Mix, Fade, Wipe, PiP, Chroma Key, Luma Key |
| Audio Inputs | RCA (Analog) + Embedded HDMI/SDI Audio |
| Audio Outputs | RCA + 3.5mm |
| Audio Mixer | Built-in Digital Audio Mixer |
| Multiview | 6-Source Multiview with Audio Meter |
| Network | Ethernet (Firmware / Sync / Control) |
| USB Ports | USB-A (Media Input), USB-C (Streaming) |
| Latency | Low Latency Switching |
| Build Type | Portable All-in-One Metal Design |
| Dimensions | 375 × 272 × 44 mm |
| Weight | Approx. 4 kg |
| Power Consumption | Approx. 33W |
| Warranty | 2 Year Manufacturer Warranty |
